Waveguide High Pass Filter

Product Model	Operating Frequency (GHz)	Insertion Loss (dB)	VSWR	Rejection Point (GHz)	Connector	Dimensions (mm)
HPF13.75-14.5GW-1153	13.75-14.5	0.3	1.3	12.75 (70dB)	BJ120	40×38×38
HPF27-31.2GW-1230	27-31.2	0.2	1.5	21.2 (30dB)	BJ320	33×19.1×19.1
HPF71-100GW-1385	71-100	3	2	68 (50dB)	BJ740	40×19.1×19.1
HPF108-137GW-1388	108-137	3	2	105 (50dB)	BJ900	40×19.1×19.1
